All Franke sinks are available as right-hand or left-hand drainer - where a sink is only available in one format this is always specified on the Specification Sheet and in our brochure. Reversible sinks automatically offer that choice.
Sinks
Generally you will need to purchase a Siphon I, II or III part plumbing kit (depending on the number of sink bowls) when ordering your sink with your retailer.
Yes. Any sink that has a 3 1/2“ waste (90mm) is capable of having a waste disposal unit connected. For Franke ceramic sinks an Extended Flange is available for Continuous Feed models. If your sink has an overflow you may need to purchase a WDU Overflow Converter, available from our service agents.
You can view videos on Franke Waste Disposal Units on our YouTube/UKFranke channel.
Many Franke sinks come with a Hygienic Overflow, which offers versatility for cleaning. Simple removal of the logo plate reveals the overflow aperture for easy, hygienic cleaning. Most Franke sinks have rigid overflow pipes and can be cleaned by pouring boiling water into them. Alternatively use a proprietary cleaner.
Despite any regulatory enforcement, in common with many sink manufacturers Franke make provision for a mechanical bond to be made to inset sink models. This is often done by utilising one of the cut-out points for the clips along the length of the clip rail. In the case of sliding clips Franke make a hole at the end of the clip rail length where the bond can be accommodated.
There are various methods of fitting a Sink undermounted. We recommend using the Fixing Clips - usually provided - with the Sink and applying them by adhering to the pictorial instructions provided with the Sink. The Clips, along with the application of silicone - not supplied - should ensure a secure and watertight fit.
There are also various styles in which an undermount Sink can be fitted: 1) Reveal - a portion of the Sink Flange is left exposed. 2) Flush - the worktop and Sink Bowl edge are aligned. 3) Overhang - the worktop overhangs the Sink Bowl. Ultimately, the manner of how the Sink is installed is down to your personal preference, but we recommend you seek advice from your installer, if you are unsure.
Physical templates are no longer available, but electronic PDF/DWG/DXF files are accessible for most sinks in the downloads section on the product page. These electronic templates, if followed, provide a 'flush' installation.
You should take into consideration the position of the overflow in the sink, as your worktop fabricator may need to router out the worktop material to accommodate it. Call our Consumer Care team and we can advise you.
Franke sinks come with a 50 year guarantee against manufacturing defect.
For more information on Franke Guarantees click here.
To enable us to process a guarantee claim, please ensure you provide us with the following information to avoid any unnecessary delay:
- Full Contact Name, Address and Telephone Number
- Proof of Purchase (please attach to email)
- Photographs showing full product and detail shots showing problem
Please complete the relevant form with this information here.
We would always recommend that you avoid the use of a plastic washing up bowl as this will over time cause the development of regular abrasion marks over the sink's surface.
Normally at your local retailer, however if you have difficulty, swatches exist for colour matching. For this service contact our Consumer Care team at Franke UK, click here.
Generally, Basket Strainer Wastes are put with a sink by a distributor when an order is received from a retailer. You should contact your retailer and they will be able to contact their distributor accordingly.
No. Stainless Steel will always scratch (whether it be of Franke's manufacture or competitor) and because of the directional polishing marks on many Franke models the scratching will show up quite dramatically initially. However, with use and cleaning using a proprietary cleaner such as Franke Stainless Steel Cleaner which you can purchase here) the stainless steel will eventually build up a patina over the years and the scratching marks will not be as evident. For more information on cleaning Stainless Steel sinks please click here.
Franke Stainless Steel Cleaner is recommended for regular maintenance of stainless steel sinks. This cleaner is easy to apply; just spread a small amount on a damp cloth, and distribute it throughout the sink with minor circular motions. Leave to work for a few moments and rinse with clean water. Afterwards, polish with a dry cloth - the Franke Microfiber Cloth is ideal. You can purchase both these products here.
You can view a video of how to clean your Franke stainless steel sink on our YouTube/UKFranke channel.
Your sink is made from high quality 18/10 chrome nickel steel. That means it’s metallurgically incapable of rusting or corroding in normal household conditions. If rust and corrosion problems do occur, tiny iron particles deposited on the surface will be the culprit. These either come from the water supply or are left behind by wire scouring pads or utensils. It’s essential to clean off these filings and dry the sink thoroughly afterwards. If you let them stick around, they’ll cause rust.
If you want to remove any rust stains from your products, we recommend using a cleaning agent containing oxalic acid (e.g. Bar Keepers Friend®). Always use mild, non-abrasive cleaning agents such as Franke Stainless Steel Sink Cleaner to remove stubborn stains from your stainless steel and make sure you thoroughly rinse away any cleaning liquids once finished. Oh, one more thing, when cleaning your stainless steel, NEVER USE STEEL WOOL PADS. We, and our stainless steel, thank you in advance.
We would point out that unless the particles are completely removed they will return. It is therefore very important that after cleaning the sink, it is dried thoroughly - a Franke Microfiber Cloth is ideal. This process needs to continue until the problem disappears. The problem is sometimes particularly obstinate to remove and it may take several attempts to restore the sink to its pristine condition.
You can purchase Franke Stainless Steel Sink Cleaner and the Franke Microfiber Cloth here.
Discoloration and most marks on stainless steel are caused by water-borne deposits clinging to its surface. One of the best ways to keep your stainless steel sink in pristine condition is to clean it with a product such as Franke Stainless Steel Cleaner, which can be purchased here. For more information on cleaning Stainless Steel sinks click here.
You can view a video of how to clean your Franke stainless steel sink on our YouTube/UKFranke channel.
As a general guide, cut inside the overall frame dimension (by inverting the sink on the worktop) by 8mm all round and always use a 20mm (important!) radius at the corners. Cut out sizes are shown on the specification sheet for each sink. If a template is provided, please use that.
Due to the nature of the backing to the glass of Glass Inset Sinks, it is important that an acid free sealant is used when installing the sink in the worktop. This prevents any reaction between the sealant and the backing to the glass. The acid free sealant we recommend – which we believe is available from Screwfix – is made by Dow Corning® and is called DOW Corning® 799 Glazing. Please refer to the installation instructions enclosed with the sink for more information.
The 3 basic measurements for comparing sink sizes are:
- Depth – distance from the top of the rim to the bottom of the sink next to the waste
- Taper – inward slope of each side of the sink from rim to bottom
- Radius – measure of the bowl’s corners & bottoms where the sides and bottom meet
The deeper the bowl, the straighter the slope and the tighter (smaller) the radius, the more capacity there is in the sink.
Advanced materials technology makes Fragranite a very tough and resilient self colour silica resin.
By following our simple care and maintenance guidelines, your sink will bring lasting colour to your kitchen throughout a lifetime of normal usage.
You can view a video of how to clean your Franke Fragranite sink on our YouTube/UKFranke channel.
OPTION 1
If you have a coloured dot on the front face of the sink, knock out the taphole as follows:
- Ensure colour sticker is in centre of pre-formed taphole.
- Take sink out of box and rest the sink vertically against your legs with the face of the sink facing outwards and ensuring the taphole is for the correct hand drainer (take care not to damage the edge of the sink in the process).
- Take a centre punch and place on the centre of the colour sticker.
- Strike the punch hard with a hammer - this will result in the core of the tap hole being knocked out.
- Finish off using the ball of the hammer and using a round file.
OPTION 2
If there is NO coloured dot on the front face of the sink, use the hole drill bit provided (FUN 112.0473.656) which is stuck to the back of the drainer next to the sink bowl. Drill out the taphole FROM THE BACK OF THE SINK.
For further information please see the instruction sheet enclosed with the sink, which can be viewed here.
You can also view a video on our YouTube channel at YouTube/UKFranke.
For day-to-day care, all you need is water and a damp cloth such as a Franke Microfiber Cloth. A fast and easy way to remove water marks, grease or soap scum deposits, is with Franke Coloured Sink Cleaner, or with a proprietary bathroom cleaner such as Ajax or Flash liquid spray, or similar products found in your supermarket.
Franke Coloured Sink Cleaner and the Franke Microfiber Cloth can both be purchased here.
Only drill Tap hole FROM TOP FACE
1. Decide on the pre- punched tap holes you require.
2. Measure to find the centre of the pre- punched tap hole required and cover the area with masking tape.
3. Using a centre punch, crack the glaze in the centre of the required hole.
4. Using a No. 8 masonry drill, carefully drill a small pilot hole from the top. NB. Only drill one small hole
5. You can then proceed to enlarge the hole to the required size by carefully using your hammer with the centrepunch.
Due to its unique coating, Tectonite sinks are resistant to all common liquids etc that are used in the kitchen (tomato sauce, vinegar, red wine etc.). The sink can be cleaned using Franke Coloured Sink Cleaner which can be purchased here, and a sponge or cloth. For more information click here.
- Tectonite is a combination of three elements:
- SMC (Sheet Moulding Compound) a glass fibre, polyester based, carrier material;
- Chemically fused 3rd Generation PiMC (Powder In Mould Coating) which gives the sink its colour, heat-, scratch- and wear and tear resistance;
- Unique texture which gives the sink its granite look.
- The sink is made by hot compression moulding with hydraulic presses.
Tectonite can withstand temperatures of up to 300°C. Despite the fact that Tectonite is very heat resistant we always advise to use a coaster when putting a hot pan on the sink.
Taps
Not necessarily. You are advised to check with the manufacturer.
Contact our service agents - click here for more information.
Occasionally a heavy tap can 'flex' on some large stainless steel sinks. This can be rectified by your tap being braced, and it is not unusual for people to have this kind of problem with a stainless steel sink, and is not a problem emanating from the sink or tap being defective in any way.
To brace the tap, you either need a piece of wood or chipboard which can be screwed across the underside of the worktop cutout and the existing tap can be fixed through a hole in this, or you can utilise a tap brace. In this way the tap is effectively secured to the underside of the strut and not to the underside of the sink, and this reduces any tendency for the sink to flex when the tap is turned on or off.
Franke also produce a patented Tap Brace which will provide a solution to the problem of 'flexing' of heavy taps on some stainless steel sink models. Fitting directly to the worktop, the tap brace has a variable collar which fits all models of taps. You can purchase the Franke Tap Brace here.
Refer to the installation instructions enclosed with your tap. . Use only a soft cloth and mild detergent. For more information on cleaning your tap click here.
Clean using hot soapy water.
Avoid using scourers or abrasive materials.
We recommend using our Franke Tap Cleaner together with Franke Microfiber Cloth to clean Franke taps. You can purchase these products here.
Simply spray Franke Tap Cleaner onto your tap, leave to work for a few moments, then wipe with a Franke Microfiber Cloth.
Never apply abrasive detergents, disinfectants or products containing alcohol, hydrochloric acid or phosphoric acid.
You can view a video of how to clean your Franke tap on our YouTube/UKFranke channel.
Tap spouts are most commonly removed by:
1.Undo the grub screw at the back of the tap
2.Unscrew the collar at the joint with the body
3.Located lug in bayonet
Flow rate can be affected particularly on the hot side of traditional vented plumbing systems. We do not recommend ceramic disc taps where there is less than 4 metre head of water. For combi boiler installations check with the manufacturer. For more information on flow rates click here.
Operationally ceramic discs can last for the life of the tap. However, mechanisms can be affected by water borne particles or hard water. To obtain replacement valve mechanisms contact our service agents.
Check the specification sheet for your particular tap. Generally they are 15mm.
Normally this is 5 years on the valve mechanisms and 1 year on the finish of the tap. Click here for detailed information on tap guarantees. Guarantees valid only on products placed and used in normal domestic situations.
To enable us to process a guarantee claim, please ensure you provide us with the following information to avoid any unnecessary delay:
- Full Contact Name, Address and Telephone Number
- Proof of Purchase (please attach to email)
- Photographs showing full product and detail shots showing problem
Please complete the relevant form with this information here.
Simply click the WHERE TO BUY link shown on each page of our website. Before visiting however, please contact the retailer to check availability of the product.
Contact our service agents.
PVD means Physical Vapour Deposition. This is an industrial process that provides a very resilient and robust finish to the tap, giving it a coating-like appearance.
NB Prior to April 2022 'Decor Steel PVD' finish was known as 'SilkSteel PVD' finish.
Franke taps are designed to complement Franke sinks, and not necessarily match exactly. Decor Steel taps will complement brushed finish appliances such as an oven and hob in your kitchen. Franke stainless steel taps such as the Eos, Panto and Valais will be a very close match to a stainless steel sink.
NB Prior to April 2022 'Decor Steel' finish was known as 'SilkSteel' finish.
The makeup of water (including the levels of chlorine) varies from area to area and this will mean that the water may taste or smell slightly different from the water that you were used too. Another reason may be due to our having to alter the treatment process slightly depending on the weather, demand and time of year. These factors all affect the levels of chlorine that we must add to the water which in turn will slightly affect the taste and smell.
Incorrectly installed water softeners, fitted to washing machines for example, can cause salty tastes and contaminate the drinking water supply. Do not drink water from water softeners because it contains high levels of salt – you should always use a tap with unsoftened water for cooking and drinking.
There are several possible causes of unusual tastes or odours in water:
TCP tastes can occur when the internal stop tap has been operated to carry out any work, or if the tap is operated after many years of not being used. Washers can start can start to degrade over time and cause TCP taste and odour problems. However this applies more to properties where the internal stop tap is more than a few years old and is seldom or never used.
Since TCP like compounds are formed when the chlorine reacts with plastic or rubber, this sometimes means that the TCP taste is more noticeable when the Chlorine level is highest. Although Chlorine is added to water continually a demand for water can mean that it may sometimes have a higher level of chlorine in it, for example, in the morning or when you get home from work.
For more information please download the PDF.
Most Franke taps require the industry standard taphole cut out size of 35mm diameter. There are several exceptions to this as follows:
- Gloriana Classic Bridge Lever - tap requires 2 x 25mm diameter tapholes.
- Gloriana Classic 3 Part set - requires minimum 30mm diameter holes x3.
Accessories
You can easily obtain additional or replacement accessories for your Franke sink, simply click here.
All-In is the flexible food preparation system for any kitchen sink (up to 540mm). Transforming your sink into a stylish and playful workstation, All-In is the flexible food preparation system designed to bring more flow to your kitchen and life.
Well-equipped and intuitive, this modular accessory system has all you need to prepare meals with ease; saving you time and space and allowing you to shift seamlessly between different tasks.
For more information on Franke All-In Accessories click here.
Please note the following points:
Place the foodstuff to process in the middle of the chopping board, not on the side. The chopping board might tip if pressure is applied to one side only.
Do not use knives made of ceramic material as this may cause damage to the surface.
The chopping board consists of tempered safety glass and is more shock and heat resistant than ordinary glass products.
Do not expose the chopping board to temperatures below 0°C or over 80°C. Do not use the product on hot plates or in ovens, microwaves, freezers or dishwashers.
Cleaning and care:
Normal staining can be removed with soap and water. Tenacious staining of the worktop should be removed with a glass rubber and then treated with a mild detergent.
Do not use cleaning products for glass ceramic hobs as these products should not come into direct contact with foodstuff.
Do not use abrasives (liquids or sponges) or aggressive detergents such as cleaning spray for ovens, bleach or other chemicals.
Franke is not liable for damage caused by improper or unsuitable use and non-compliance to the above cleaning instructions.
The Hygenia Chopping Board is made of Polyethylene, is extremely durable, and is capable of being washed in the dishwasher. It is heat resistant up to a maximum of 100°C, however under certain circumstances very hot utensils may brown the surface. As an oil based product it is not scratch resistant, and the surface will abrade over time.
Wood is a natural product it is therefore subject to absorbing moisture, and if the quantities of moisture are not equal on both sides it can bow especially so when the product is first used.
However, this can be corrected by wetting the board on both sides and leaving it to dry overnight on a flat surface with the convex side uppermost. This is most conveniently done with the board placed over the bowl.This enables the warp to drop out and as the board gets more use it will eventually stop warping. We also recommend occasional oiling of the board with a good quality vegetable oil, to make the surface more water-resistant. Do not put the board near a heat source and do not put it in direct sunlight to dry.
The life of the basket very much depends on the type of use it receives, and we notice that some customers choose to use the basket in the sink for washing-up purposes (for which it was not designed). If the basket is used in this way its life is considerably shortened due to the constant immersion in hot water. This softens the plastic coating which then becomes susceptible to piercing by sharp objects such as knives, forks etc. When water penetrates onto the metal frame it rusts and subsequently the plastic coating cracks and breaks away and if used in this manner it does mean that the life of the basket is considerably shortened.
You may wish to add water to thicker concentrated liquid soaps, in a 1/3 water to 2/3 ratio to reduce the possibility of clogging. Regular cleaning of the soap dispenser is also recommended.
You should avoid anti-bacterial soaps, as these can cause corrosion of your dispenser over time.
Instant Boiling Water Taps
We have found that we come across a few common issues that affect the performance and efficiency of boiling water taps. These issue can be dealt with during or following installation, with guidance available by following the link below
Click here to view the guide.
Yes. Both systems provide instantaneous, true boiling water
Yes. As Mythos and Maris taps fit in a standard 35mm tap hole, they can be retro-fitted to replace an existing tap. You can view videos on our YouTube/UKFranke channel
No. The Mythos, Maris, Minerva and Omni taps can be installed in a standard 35mm diameter tap hole.
No, using a kettle will be a thing of the past and you will wonder how you ever managed without a Mythos and Maris Water Hub Instant Boiling Water tap!
The Mythos and Maris Water Hub taps must be fitted with the boiling water handle on the left.
For the Maris Mechanical version, the handle should be pulled out and twisted away to engage the boiling water function. For the Maris Electronic and Mythos, the handle should be tapped, twisted away and then double tapped to engage the boiling water function.
The functions of the Filter Cartridges compatible with the Mythos and Maris Water Hub systems are to protect the system from the build-up of water-borne deposits, notably limescale, and to remove chlorine to improve the quality of the boiling water supply.
Maris Water Hub: Franke 5-in-1 & 6-in-1 Tap Spares (central-servicesuk.co.uk)
Mythos Water Hub: This Filter is a variation of a Pro-M, as it has a chip fitted to show how long the Filter has been in use for. Franke 5-in-1 & 6-in-1 Tap Spares (central-servicesuk.co.uk)
We recommend the frequency the filter cartridge is replaced is based on the hardness of the water supply, in order to maintain performance and efficiency of the product. For further details, please contact Franke on 0161 436 6280 Monday to Friday 9am-4pm or by emailing ks-hotwater.gb@franke.com. Alternatively, refer to the product manua
Ultimately, regardless of which boiling water tap you have, the Filter Cartridge should be replaced based on the hardness of the water supply.
Mythos and Maris Water Hub – 12 months maximum. 4-in-1 versions of the Maris and both Mythos taps have a filter reminder function on the tap.
For further and more definitive guidance concerning how frequently the Filter Cartridge should be replaced, please contact Franke on 0161 436 6280 Monday to Friday 9am-4pm or by emailing ks-hotwater.gb@franke.com. Alternatively, refer to the product manual.
Maris heating tank dimensions = 229mm base diameter x 340mm high
Maris filter housing inc cartridge dimensions = 100mm diameter x 300mm high
Mythos heating tank* dimensions = 200mm (wide) x 525mm (deep) x 440mm (tall)
*The filter cartridge is contained within the heating tank
Voltage: 230 VAC
Power: 2100 W (+5% / -10%)
Load: 9.2A
Standby mode max.: 14W
Maris = 1 (14.5 psi) – 5 bar (72.5 psi)
Mythos = 1 (14.5 psi) – 5 bar (72.5 psi)
For a satisfactory performance the Maris and Mythos Water-Hubs requires a minimum water pressure of 1 bar (14.5psi). Whilst the Tap cold and boiling water, the flow of the hot supply is unlikely to be considered satisfactory and also result in difficulty achieving mixed water. If your hot water pressure is too low, we recommend that you install a suitable booster pump.
The reheat times for both the Mythos and Maris Water Hub boiler is 8-0 minutes.
The boil dry function will be activated and the boiler will not heat up. Remove the power supply for 1 minute and restart the installation.
Operating our taps are easy, check our videos bellow.
Franke Mythos Water Hub - All In One - Tutorial Controls (youtube.com)
Franke Maris Water Hub - Electronic Taps - Tutorial Instant Boiling Controls (youtube.com)
Franke Maris Water Hub - Electronic Taps - Tutorial Filtered Water Controls (Optional) (youtube.com)
Franke Maris Water Hub - Mechanical Taps - Tutorial Instant Boiling Controls (youtube.com)
Please follow the links below to view installation guidance videos for our boiling water systems:
Franke Maris Water Hub - Mechanical Taps UK - Installation - Solo (youtube.com)
Franke Maris Water Hub - Mechanical Taps UK - Installation - Complete (youtube.com)
Franke Maris Water Hub - Electronic Taps UK - Installation - 4-in-1 Solo (youtube.com)
Franke Maris Water Hub - Electronic Taps UK - Installation - Solo (youtube.com)
Franke Maris Water Hub - Electronic Taps UK - Installation - Complete (youtube.com)
Franke Mythos Water Hub - All In One - UK Installation (youtube.com)
There is an option for the Maris to be fitted without a hot water supply, with guidance to install available in the link below:
Whilst the materials the Taps are manufactured from are robust and durable, we recommend they are cleaned with Franke Tap Cleaner and applied with a Franke Microfibre Cloth. Alternatively, warm, soapy water can be applied with a soft, clean cloth.
Yes, however the softened water must only be used for the hot and cold supply, not to supply the filtered cold and filtered boiling water, as the usual method of softening – sodium added to the supply – will have a detrimental effect on the performance and efficiency of the Filter Cartridge.
It is good practice to ensure the environment in which the boiler is fitted is ventilated. We recommend several holes are drilled in the carcass, if pre-existing adequate ventilation is not available
The Maris and Mythos Taps dispense boiling water at the outlet of the spout and, as a consequence, there will be some splutter, steam and noise. In fact, the water spitting and spluttering when dispensed is an indicator the water is at boiling point.
This can be quite off-putting at first, but any concerns are quickly dispensed with once the simple technique for operating the boiling water is understood.
We recommend the receptacle is placed directly beneath the Spout, with the Spout contained within it, in order to contain boiling water and mitigate the chance of it contacting you.
Hard water has a detrimental effect on the performance and efficiency of the product, with the Filter Cartridge supplied mitigating build-ups that can accumulate through the system.
It is imperative, both from a Guarantee and performance basis, that the Filter Cartridge is replaced when recommended as the per guidance present in the product literature, based
on the hardness of the supply. Please contact Franke on 0161 436 6280 or ks-hotwater.gb@franke.com for further guidance and/or clarification.
You can find full details of the Franke warranty here: Franke Home Solutions – Quality Guarantee
To make a claim, please complete the relevant form with this information here. You will need:
Full Contact Name, Address and Telephone Number
Proof of Purchase (please attach to email)
Photographs showing full product and detail shots showing problem
The Water Hub system is intended for use in domestic and similar environments, such as: - Staff kitchens in stores, offices and other working environments; - By guests in hotels, motels and other similar residential environments; - Bed and breakfast accommodation and other similar residential environments
It is good practice to turn the system off at the mains and drain the heating tank of water by opening the boiling water supply control on the Tap. Upon your return, simply turn back on at the mains and refill the tank with water – this will result in a small wait for the water to reboil.
Vital Capsule Filter Taps
The Vital Capsule Filter system gives you 500 litres of the purest drinking water can be dispensed through the patented Vital filter capsule, before a discreet LED light tells you that the filter needs changing. This is done in seconds, with a simple twist and turn of the capsule housing.
- HYGIENE : purified water without the risk of bacterial growth (the case with the filter jugs that must be kept in the refrigerator).
- ENVIRONMENT : Elimination of the need for plastic bottles.
- SAVINGS : an investment amortized in a few months and a drastic reduction in the cost of water.
- SPACE SAVING : no installation required in the kitchen cabinet (no tools required).
- TIME-SAVING : no need to wait, purified water is available instantly.
- CONVENIENT : no carrying and storing of bottles of water.
Nanofiltration allows the retention of all dissolved pollutants, whether biological, organic or mineral. Benefits include:
- Removes 99.9% of bacteria
- Removes 99.9% of viruses
- Filters out rust and sediment
- Filters out microplastics
- Removes tastes and odours
- Hygienic
From April 2022, your new Vital Capsule Filter Tap is supplied with two filter cartridges; the usual High Performance filter and also a new High Flow filter, giving consumers the chance to understand their water quality, and to use the correct filter for their needs.
With the new addition of the High Flow filter, consumers can now get the state-of-the-art in water filtration with a filter designed to work in balance with their home’s requirements. The original High Performance filter is better suited to new build homes with more modern pipework whereas the new High Flow filter is the best fit for homes with older pipework where sediment may be a problem.
Giving consumers both filter choices in the tap box will essentially allow them to decide which is the right option for their home and then continue to purchase the correct replacement filter going forwards.
A filter should last an average of 3-4 months. Replacement filters are available to purchase from Central Services.
Vital Capsule Taps have an LED light to indicate when the filter needs to be replaced. A green light indicates that the filter cartridge is working. A red light indicates that the cartridge has filtered 450 litres, and it should be replaced as soon as possible. A flashing red light and reduced flow indicates that the cartridge has filtered 500 litres and needs to be changed.
The timer is powered by a CR2032 battery (lifetime 3 years).
Unscrew the filter housing and remove the old cartridge. Insert new cartridge, screw the filter housing back into place. Reset the electronic timer button. After flashing for 3 seconds, your filtered water is ready to be dispensed.
If you have mispaced your reset key, replacements can be purchased from Central Services.
Yes - the box measures just 16 x 12 x 4cm.
The Vital Capsule system has the smallest and first filter cartridge that combines bionic membrane and active carbon:
PRE-FILTRATION : a first filter captures the large impurities and holds them back.
MEMBRANE : thanks to nanotechnology, a 0.06mm membrane covered with a fine nylon mesh filters the smallest particles, and even bacteria.
ACTIVE CHARCOAL FILTER : It captures all dissolved impurities, such as chlorine. This technology is a natural physical process that has been proven for decades.
PURE WATER : after passing through this multiple circuit, it flows with a simple movement of the hand into your glass.
All Vital taps are supplied with both a High-Performance filter and High Flow Filter as standard, for those rare occurrences where an enhanced water flow rate is required, Franke have developed the High-Flow filter which is a superb alternative providing continuous high flow rates in areas where the High-Performance filter can get congested prematurely due to excessive sediment contamination in the water.
The High-Flow filter has a mesh size that is 20 times finer than ordinary household filters. As a result, rust, dirt and fine sediments are filtered out for cleaner water. Please note, the High-Flow filter does not remove microbial cysts, microplasts, bacteria & viruses.
This is nothing to worry about. Along with some air, the first water through a new cartridge flushes out some dust in the activated carbon filter.
The Vital Capsule Filter 3-in-1 J-Spout and Semi-Pro models require an industry standard taphole of 35mm.
The Single Dispense model is designed to take advantage of a soap dispenser hole of 22mm, but there is an adapter kit for a 35mm hole included.
The flow rate of the filtered water is 2 litres per minute at 2 bar., and 3.5 litres per minute at 3 bar.
Vital Capsule Taps operate between 0.7 bar to 6.8 bar pressure.
When the filter tap is first turned on, air has to be pushed out of the filter before the water flow is established. This is perfectly normal and not something to be concerned about.
A Vital Capsule Range Chiller Unit available. The Chiller is a compact, stainless steel design, is silent to run, and is simple to install.
The unit measures 34.5h x 19.5 w x 29d cm, and has a capacity of 2.5 litres. The operating temperature of the Chiller is 5-12 degrees, and it takes approximately 1 hour to chill from being turned on initially.
NB The Vital Chiller is no longer available to purchase.
The power consumption is 173 Wh/day which is equivalent to 0.173 kWh/day. Annually this is 63kWh. The cost per year would be 63 x 0.236p = £14.87.
(Average price of unit of electricity in the UK from www.nimblefins.co.uk)
The Franke Vital capsule system saves around £453 per year for an average family because:
The average 4 person household consumes 3,000 litres of water per year. At an average mineral water price of £0.45 per litre, this yields costs of £1350 per year versus £150 per year for 6 Vital filter capsules.
Vital Capsule Taps are guaranteed for 1 year on the finish, and 5 years on valves, with 3 years on the filter light battery. The Chiller unit is guaranteed for 2 years.
To enable us to process a guarantee claim, please ensure you provide us with the following information to avoid any unnecessary delay:
- Full Contact Name, Address and Telephone Number
- Proof of Purchase (please attach to email)
- Photographs showing full product and detail shots showing problem
Please complete the relevant form with this information here.
Franke FilterFlow
Your Franke FilterFlow system will remove and reduce a wide range of possible contaminants from tap water. These include –
- Chlorine
- Harmful bacteria and cysts eg Cryptosporidium, Giardia
- Heavy metals eg lead
- Other chemicals eg pesticides, herbicides
- Dirt, sediment, rust and other debris
Absolutely! Everyone’s water is different, but most people can taste the difference between tap and water filtered using a Franke FilterFlow system immediately. Odours and unpleasant tastes will be gone, sediment, rust or other kinds of dirt will have been trapped by the ceramic in the filter system’s cartridge and you will have protection against harmful bacteria and cysts. It is likely that you will find tea, coffee and other hot drinks much more pleasant. But most importantly, you will enjoy the peace of mind that comes from drinking water that is refreshing and just as nature intended it.
Whatever style of tap you choose, your Franke FilterFlow system will have a stainless steel or durable ABS cartridge housing, which is fitted in the cupboard underneath your kitchen sink. Inside the housing is the unique Franke FilterFlow 03* filter cartridge, which is made from ceramic and carbon. When you use your tap, cold water is diverted through the filter cartridge, removing a wide range of possible contaminants. The filtered water is then ready to be dispensed via your tap.
The cartridge’s ceramic outer shell works to trap dirt, sediment and some types of harmful bacteria – some so microscopic that they are invisible to the human eye. Meanwhile, the cartridge’s inner core of carbon tackles unpleasant odours and tastes – for instance, chlorine.
Ceramic and carbon are proven filtration media and have been used safely for many, many years to effectively filter and cleanse water. By combining high quality micro porous ceramic and solid carbon together into one filter cartridge, the Franke FilterFlow system delivers an enhanced, comprehensive filtration performance that is far superior to many of the domestic filter taps and systems available today.
* Please note, the standard Franke FilterFlow filter cartridge is the Franke 03, which is comprised from both ceramic and carbon. However, due to localised water type, Franke FilterFlow systems supplied to Northern Ireland are likely to use the Franke 04 cartridge, which is made purely from carbon. Depending upon water quality, further alternative Franke FilterFlow cartridges are also available – please contact Franke FilterFlow for details.
For more information on the Franke FilterFlow system please click here.
The Franke FilterFlow system is simple to install – it’s an easy, straightforward job for any plumber. Following installation, all you need to do is maintain the performance of your system is to replace the filter cartridge every 6 months. This is a simple procedure that – thanks to the Franke FilterFlow’s ‘easy-open’ housing and quick-fit cartridge are well within the scope of the average householder.
The Franke FilterFlow system is remarkably compact. The stainless steel housing measures 29cm high x 7cm wide x 9cm deep, and is usually fitted in the cupboard underneath the kitchen sink. The system’s hoses are similarly neat and unobtrusive – leaving plenty of storage space for all the usual undersink necessities!
We recommend that filter cartridges should be replaced every 6 months. When you purchase your Franke FilterFlow system, please ensure you register it immediately. Registration can be completed online or by filling in and returning the registration card that is included with every Franke FilterFlow system. Registration will enrol you on the Franke FilterFlow replacement cartridge reminder scheme and extended parts guarantee.
Genuine replacement cartridges for your Franke FilterFlow system can be purchased online at www.frankefilterflow.co.uk, by emailing info@frankefilterflow.com or by calling 01603 875 468. Using official Franke FilterFlow cartridges will ensure both your peace of mind and that your flow of filtered water remains uncompromised. Authentic Franke FilterFlow cartridges are instantly recognisable by their use of patented red caps that are exclusive to Franke.
It is not possible to use the new Franke FilterFlow cartridges in Franke Triflow systems. However, it is possible to purchase an upgrade kit to replace the plastic or stainless steel housing of an existing Triflow tap with the latest Franke FilterFlow stainless steel housing. This is a complete kit that comprises of the latest stainless steel Franke FilterFlow undersink cartridge housing, stainless steel braided hoses and all connectors. Upgrading your Franke Triflow housing (whether stainless steel or plastic) is simple and straightforward – and will allow you to use quick-change Franke FilterFlow cartridges.
The Franke FilterFlow 03 filter cartridge supplied as standard with your Franke FilterFlow system will not resolve what are essentially cosmetic concerns relating to water hardness – namely limescale and surface residues on hot drinks. In fact, the standard Franke 03 filter cartridge was designed primarily with health and security in mind and as such, actually retains calcium and magnesium. Both elements are regarded as beneficial for health, not to mention vital contributory factors to pleasant tasting water.
However, we do recognise that for some at least, hard water and limescale can be unpleasant. If you wish to address this, we would suggest changing your Franke FilterFlow system’s cartridge to an Franke 06 ‘Carbon De Alk’ cartridge at your first cartridge change. In addition, please note that the material used to make teabags can contribute to surface ‘scum’ on hot drinks. We recommend using traditional tea leaves and/or teabags that have been especially formulated for hard water areas, such as ‘Tetley’s’.
Your Franke FilterFlow system relies upon water pressure to push water through the filter cartridge. However, there is no requirement for higher-than-average pressure. A minimum pressure of 1.5 bar / 23 psi is required. On no account should water pressure exceed 6 bar / 90psi.
If you are unsure of your water pressure, a qualified plumber will be able to measure it for you. If it is too low, your plumber will be able to advise you about fitting a small booster pump – or conversely, a suitable pressure reducing pump if the pressure is too high.
Based on pressure of 3 bar/45 psi, your Franke FilterFlow system should deliver 1 litre of water / per 25 seconds. For optimum performance, we recommend adjusting the stop valve on your system to allow a delivery of 1 litre of water/per 30 seconds.
Yes – the housing system and components of your Franke FilterFlow are guaranteed for 5 years from the date of purchase.
Guarantees valid only on products placed and used in normal domestic situations.
For full guarantee details, please contact –
Customer Services
Franke FilterFlow
3 Old Winery Business Park
Chapel Street
Cawston
Norfolk NR10 4FE
Telephone: 01603 875 468
Email: info@frankefilterflow.com
Website: http://www.frankefilterflow.co.uk/
Waste Disposers
One of the advantages that the Franke Turbo Elite Permanent Magnet Motor disposers have over standard Induction Motor WDUs is the starting torque - Franke Turbo Elite WDUs are up to full speed within the first revolution.
Most jams occur at start-up because food waste will be stuffed into the disposer until it is full (this is not the correct way to use the disposer but is more reality).
The Franke Turbo's initial high starting torque gives it the advantage to break through the waste already put into the disposer. Under similar conditions an induction motor disposer can jam as it tries to push the waste around while it builds up speed. When the induction type motor cannot push any more and becomes jammed the "Auto Reverse" feature gives the ability for the unit to run in the opposite direction to break away from the jam condition.
You can view videos of Franke Waste Disposal Units our YouTube/UKFranke channel.
As the overflow would normally connect to the Basket Strainer Waste, you need to purchase either a WDU Connector for a single bowl sink, or a WDU Converter for a bowl and a half sink. These can be purchased from our service agents here.
A Franke Turbo Elite Waste Disposal unit consumes roughly the same power in one month to lighting a 100 watt light bulb for one hour, therefore operating costs are relatively low. The high torque fast grinding Franke Turbo units use very little water.
A Batch Feed model is activated by loading the chamber and rotating the WDU plug. Continous Feed models are operated by an Air Switch (or alternative) and waste is fed through the open neck of the unit. In both cases, a continuous supply of water is necessary whilst the WDU is in use.
Franke Turbo Elite Waste Disposal Units featured on this website carry a 10 year guarantee. This excludes the TE-45 model which carries a 3 year guarantee. For further information see our Guarantee page.
To enable us to process a guarantee claim, please ensure you provide us with the following information to avoid any unnecessary delay:
- Full Contact Name, Address and Telephone Number
- Proof of Purchase (please attach to email)
- Photographs showing full product and detail shots showing problem
Please complete the relevant form with this information here.
The procedure is as follows:
- With the disposer mounted on the sink and line cord connected to a wall outlet receptacle, turn "ON" the wall mounted switch.
- If the disposer is "OFF", depress air switch actuator to turn the disposer "ON".
- With the disposer " ON " pull air switch hose from disposer connectionn and discard air switch actuator and hose.
- Turn the disposer "OFF" by turning off the switch, usually controlled by a wall mounted switch.
- Operation of disposer is now controlled in a typical manner by the wall mounted switch.
The Franke air activated control switch button operates continuous feed waste disposal units from a point determined by the consumer, eg on the worktop or possibly even within the sink perimeter.
Air switches are safer than electric switches because they keep the electricity away from the users' hands. The air switch control mechanism usually mounts under the sink (or is incorporated into the Waste Disposal Unit itself), where it remains dry. From the activated control switch button, an air tube connects with the switch controller, which in turn operates the unit.
The benefit is that the operational switch avoids the necessity to have a wall mounted toggle switch (which itself is electrical), and is therefore neater and safer to operate .
Disconnect the tube from the air switch button, then blow down the tube which should engage the waste disposal unit. Reconnect the air switch button.
Hobs
Franke genuine spare parts are provided by our service agents.
For in guarantee and out of guarantee repairs please contact our service agents.
Induction hobs generally have an absorption higher than the power of 3 kW available at home. However, to allow the use and containment of Franke consumptions (on some models of the range) it allows the setting of the highest absorption level of the induction hob. It is logical that reducing power limits the ability to exploit the product to maximum performance.
Induction cooking hobs require the cooking pot or saucepan to have a diameter bigger than a certain dimension, which is specified on the product instruction booklet.
The induction hob operates by means of a magnetic field that generates heat on the bottom of the pot when the latter is placed in contact with the surface of the plane. The pot used on this type of cooking stove must be made of special material containing iron and its bottom must be smooth for optimum yield of the inducer. Non-magnetic, aluminum or copper stainless steel pans as well as terracotta or ceramic pans are not suitable for use with induction.
The great benefit of an induction hob is fast cooking times. For example, boiling water for making pasta is much quicker than using a gas hob. .Other benefits include the easy to clean flat glass surface. Another important factor is the digital touch controls for maximum safety and the various customisable cooking zone options.
We advise you to clean your hob when the surface is still warm and the residual heat indicator lamps are off. Firstly, use a scraper to remove any food residue, taking care not to scratch the surface of the glass; then rinse with water and dry well with a clean cloth. We then recommend the use of Franke Hob Cleaner which can be purchased here, this product effectively removes dirt and burnt-on food from your hob, ensuring thorough cleanliness and care.
A ceramic hob works by means of radiant electrical resistors, placed under the glass that diffuse the heat in the corresponding cooking zone. An induction hob, on the other hand, operates by means of coils (inductors) that trigger a magnetic field only if the pot (with iron base) is placed on the hob surface at the selected cooking zone.
The bridging function allows two individual cooking zones to be switched on and adjusted together. Ensure that the power is switched on and simply press in the middle of the power scale of each zone simultaneously, this will show a"[" on one side and "]" on the other to signify the zones are bridged.
It is normal for the hob to produce humming sounds when boiling or cooking. Different types of cookware may produce slight sounds such as buzzes or hums. Lighter weight stainless steel pans produce more noise than heavier pans, like enameled cast iron.
Induction hobs are a very energy efficient way of cooking. They do not produce any heat themselves, but cause the pan to become hot through their electromagnetic induction. This lack of extraneous heat however does have a side effect in that there is no hot air, as you would find in a conventional electric or gas hob, to warm any cold surfaces that water vapour from what is being cooked may come into contact with. Consequently, some of the water vapour and steam produced by the cooking process will condense on these cold surfaces. The amount of condensation on any particular surface will depend on many factors including the ambient temperature in the kitchen, the ambient temperature of the surfaces, the thickness and material from which the surface is made and the type of cooking.
You should consider a hood model designed to combat condensation, such as the Maris Drip Free or the Atmos Steam Off.
Select a zone on the left hand side of the display, then use the Slider.
The hob will automatically detect an additional pot in the same zone, or you can deactivate a zone and set it to a different temperature/function.
When you first switch on the hob, you have 10 seconds to set the PowerLimiter level.
You can select these functions in the main menu, along with more functions. (NB for the Maris 2gether it only has these 4 functions).
The Booster Function only operates for a certain time, before dropping down to the maximum level.
Hoods
Refer to the instruction manual for your hood; the flashing light may be able to be turned off simply by resetting the controls. You can download instruction manuals from our Expertise section.
Firstly, check that your installer has fitted the hood according to the instructions in the installation manual supplied with the hood. If the installation is correct and the vibration or noise seems to come from the product itself, please contact our service agents.
Firstly, check that your installer has fitted the hood according to the instructions in the installation manual supplied with the hood, and that the hood itself is suitable for the size of the room. (An effective hood must be powerful enough to change the air in the room 10 times an hour, when in operation. The extraction rate of each hood is shown in our brochure and on our website). If the installation is correct and the low extraction seems due to a defect with the product itself, please contact us.
Please ensure you provide us with the following information to avoid any unnecessary delay:
- Full Contact Name, Address and Telephone Number
- Proof of Purchase (please attach to email)
- Photographs showing full product and detail shots showing problem
Please complete the relevant form with this information here.
The noise of a hood is generated by the airflow that passes inside it during operation. The internal components of our hoods have been built so that the airflow finds few obstacles to its passage, with excellent results in terms of effectiveness and low noise emission. An effective way of avoiding the increase in noise is to use, for the outflow of air, well-sized pipes (120-150 mm in diameter). Dirty or saturated filters can hinder air flow: Periodic cleaning (or replacement) of filters ensures smooth air flow.
The hood must be installed at a minimum distance of 65cm from the hob. We recommend that you do not install it more than 75cm from the hob to properly remove vapours and steam. NB Some angled hoods are required to be fitted at a height of 45cm from the hob. Always check the Installation Instructions for your hood to check the correct distance required.
Choose pipes of 150mm in diameter (or no less than 120mm), with a ducting length of no longer than 3-4 metres, and with a maximum of 2 curves. WARNING: The guarantee does not cover any damage caused by failure to observe minimum safety distances.
It is preferable to install a hood on an outside wall, as this is the most effect and quiet solution; emitting polluted air outside via ducting, and drawing in new air. However, hoods can be installed onto party walls, or suspended from a ceiling. To install a hood in recycling mode (ie with no ducting to outside) a Charcoal Filter must also be purchased - these can be obtained by contacting Central Services.
The model of hood is detailed on the label within the product (accessible by removing the metal / grid filters) with a code in the upper right of 7 or 9 digits starting at 63 ..., or a code of 10 digits with 110.xxxx.xxx format.
Your retailer or installer should check the hood either directly during installation or when the box is opened. Subsequent complaints can not be recognised as guarantee claims via our service agents.
Simply use a soft cloth and a neutral, chlorine-free detergent such as Franke Cooker Hood Cleaner. Thanks to its professional formulation, Franke Kitchen Care cooker hood cleaner effectively eliminates grease deposits and odours from your cooker hood, ensuring perfect cleanliness inside and out. You can purchase this product here.
Filters are an integral part of the hood, their maintenance affects the efficiency, safety and noise of the hood. Anti-grease filters protect the engine from the grease contained in vapours extracted by the hood. The metal filters on Franke hoods filter a high level of fat particles. To keep them efficient, just wash them by hand or dishwasher, on average every 2 months. Synthetic filters, possibly on some old models, are not washable and should be replaced when fat impregnated, about every 2 months. The odour filters are activated charcoal cartridges to be installed exclusively on hoods fitted in reciculatory mode. They are not washable and should be replaced periodically, on average every 3 months.
A ducting diameter of 150mm is recommended as the ideal for hoods with a capacity of 300 mc / h or hight. If it is not possible to install this diameter of ducting, we recommend a 120mm diameter pipe. Smaller pipes adversely affect the flow rate and noise of the hood.
An effective hood must be powerful enough to change the air in the room 10 times an hour, when in operation.
To decide which hood to choose, first calculate the volume of the room. This figure can be arrived at by multiplying room length x width x height. So a kitchen that is 4 x 4 x 2.5 metres has a volume of 40 m3.
This room volume figure is then further multiplied by 10 to obtain the optimum rate of airflow for that room, based on the need to change the air ten times an hour. So a kitchen of 40 m3 x 10 = 400 - meaning it would require an extraction rate of 400 m3/h for efficient ventilation of the room.
Induction hobs are a very energy efficient way of cooking. They do not produce any heat themselves, but cause the pan to become hot through their electromagnetic induction. This lack of extraneous heat however does have a side effect in that there is no hot air, as you would find in a conventional electric or gas hob, to warm any cold surfaces that water vapour from what is being cooked may come into contact with. Consequently, some of the water vapour and steam produced by the cooking process will condense on these cold surfaces. The amount of condensation on any particular surface will depend on many factors including the ambient temperature in the kitchen, the ambient temperature of the surfaces, the thickness and material from which the surface is made and the type of cooking.
You could consider an Anti-Condensation model of hood such as the Atmos which is especially designed for use with induction hobs, which keeps your kitchen dry by capturing steam and fumes before they condense on surfaces.
You should always aim to fit an angled glass hood at the height specified in the Installation Instructions (typically 450mm above the worktop, but the exact measurement is always specified in the Instructions) to ensure optimum efficiency. If you choose to fit the hood higher, eg for aesthetical reasons, then this is your choice, however you will appreciate that if the hood is fitted higher than recommended, then it's performance will decrease accordingly.
Contact us on 0161 436 6280.
Ovens
A new oven, when first switched on, always emits odour due to manufacturing residues. Before starting to use it for cooking food, it is good practice to heat the empty oven at maximum temperature for about 1 hour, opening a window to ventilate the room.
The oven cooling fan continues to work for a while even after it is switched off, to decrease the internal temperature quicker.
The Pyrolytic function is an automatic cleaning function that, thanks to the high temperature reached, is able to burn off dirt and grease on the cavity walls. Throughout the pyrolytic process, the door remains locked for total safety. At the end of the cycle, when the cavity has cooled down, it is sufficient to simply clean the interior by removing dirt and grease burned with a sponge and then with a microfibre cloth.
Under normal oven use, simply run the Pyroltyic function once a month. However, if you bake frequently or you bake large quantities of food, it is advisable to run the Pyrolytic cycle more frequently.
There is one set of telescopic guides provided on the ovens allow you to easily introduce and extract safely baking trays or grids, as well as more conveniently control cooking.Additional Set of telescopic guides are available to purchase from Central Services.
Use glass cleaner and a soft cloth or sponge. Pour the glass cleaner onto the cloth or sponge, do not spray it directly onto the control panel. Do not use abrasive detergents, steel wool, rough sponges, or some types of absorbent paper that could damage the surfaces.
The recipe option prompts you as to what to do, as well as setting oven correctly and which shelf to place food on. See User Manual for more information.
The Cook Assit Pro feature contains additional recipes which can be customised with different foods. This feature is available on both pyrolytic and steam ovens.
You can use as few or as many levels as needed.
Yes, they act in the same way.
The Maxi Cooking setting should be used to cook large joints of meat, whole turkey etc.
There is a special programme to empty the water tank via a pipe. The oven will not work again until this is done, so needs to be done after every steam cooking session.
The touch control oven is fully automatic, and the manual control oven is semi-automatic, also there are fewer functions/recipes on the manual model.
The first prompt is just a suggestion, the second prompt is to confirm the selection.
Microwaves (Combi)
Dirt and grease are the cause of sparks in the microwaves, as well as the use of metal elements. Carefully clean the inside of the appliance, preferably with a detergent specifically for microwave ovens. Be careful to only use dishes and containers suitable for microwave use.
Try resetting the equipment by pulling the plug out of the socket for about 1 minute to briefly turning off the power supply.
Check that the plate has not been overloaded: the maximum capacity of the turntable is 1.5kg. Check that the microwave oven is clean: moisture or fat at the bottom of the appliance may prevent the dish from turning easily. Check that the plate has been properly positioned: the swivel plate must be positioned in such a way that the rollers fit into the bottom of the metal groove.
Check for the presence of mains electrical power and whether the microwave is connected to the electricity supply. Turn off the oven and restart it to see if the fault persists. If the microwave does not restart, this could be a power cut.
The cooling fan is active, open the door or wait until the cooling process has finished.
The quick heat feature, is used for quickly reheating the oven before a cooking cycle. Wait for the function to finish before placing food inside the oven.
You can press the 'X', symbol at any time to pause the function. Simply reselect and apply the settings you require, press start symbol to activate the correct function.
There is a table in the User Manual which states the optimum power for certain types of food and the length of time to warm up or cook.
Choosing a Retailer
Franke UK Ltd believes that excellent service before and after the sale is an integral part of the Franke experience. We strongly encourage you to thoroughly research any retailer before making a purchase to ensure that you are getting what you expect, and the service and support that Franke strives to deliver.
To view a list of companies are authorised to sell a selected range of Franke products online click here.
General FAQs
Please contact our office by email ks-info.gb@franke.com or by telephone on 0161 436 6280.
Go to the Brochure page on this site. Franke Retailers should contact their Distributor to obtain brochures.
If you would like a brochure pack to be posted to you please complete the Contact Form with your address details.
Contact our service agents more information.
Please contact us directly using our Contact Form.
